1059210H
CS10.070.40.0070.DA
CS10.070.40.0070.D.A
14814985
CS1001
SC10
Attachment type on bottom side: cross bore
Attachment type rod side: without
Installation dimension (mm): 255,5
FI casing tube (mm): 89
FI mounting bottom side (mm): 30
FI mounting rod side (mm): 30
FI piston rod (mm): 40
Weight (kg): 12,376
Operating pressure (bar):185
Piston FI (mm): 70
Brand Haco
Stroke (mm): 63,5
Oil connection bottom side: 3/8 inch internal thread
Oil connection rod side: M 10x1
ZA TIPOVE:
DHLM.20
DHLM50
PODIZNA RAMPA KAMIONA, DIJELOVI PODIZNE RAMPE
BAR CARGOLIFT DIJELOVI
DIJELOVI KAMIONSKIH UTOVARNIH RAMPI
PODIZNA RAMPA ZA KAMIONE
DIJELOVI UTOVARNE PODIZNE KAMIONSKE RAMPE
