234/1
02342001001A
61102599400
-------------
Assembly flange drive
4-hole 80x80 mm
Brand
Meiller
Construction form
straight
Delivery rate (cm3/r)
17,5
Direction of rotation
left
right
Direction of rotation changeable
no
Material housing
cast steel
Max. pressure (bar)
400
Max. revolution (rpm)
2400
Operating pressure (bar)
400
Pressure connection
M 22x1.5 internal thread
Specification drive
shaft 8x32x36
Standard drive
DIN 5462
Suction connection
M 45x2 internal thread
Weight (kg)
8
