02952001010
295/10
61102597100
-----------
flange turned 45° for Mercedes gearbox with auxiliary drive 3/90-2c or 3c max. pressure 200 bar, torque 300 Nm
Assembly flange drive
4-hole 80x80 mm
Brand
Meiller
Construction form
straight
Delivery rate (cm3/r)
78
Direction of rotation
left
right
Direction of rotation changeable
no
Info 1
flange turned 45° 300 Nm permissible
Material housing
cast steel
Max. pressure (bar)
200
Max. revolution (rpm)
1800
Operating pressure (bar)
200
Pressure connection
M 27x2 internal thread
Specification drive
shaft 8x32x36
Standard drive
DIN 5462
Suction connection
M 45x2 internal thread
Weight (kg)
17,7
