0510425009
11021802
R918C00356
209130056 STEYR
209130134 STEYR
209130135 STEYR
AZPF-11-008RCB20MB
62000034000
1PN082CST3/453
--------------
Weight (kg)
3,37
Brand
Bosch-Rexroth
Operating pressure (bar)
250
Manufactured size
F
Max. revolution (rpm)
4000
Max. pressure (bar)
280
Material housing
aluminum
o shaft/hub (mm)
17
Center o flange (mm)
80
Direction of rotation
right
Version
single pump
Delivery volume (cm3/r)
8
Specification drive
shaft conical 1:5
o suction connection (mm)
20
Mounting suction connection
hole circle 40 mm M 6
o pressure connection (mm)
15
Mounting pressure connection
hole circle 35 mm M 6
Optional equipment valve
without valve
Assembly flange drive
rectangular flange o 80 mm
