60300110803
1536604
603-001-10803
02702001080
270/80
------------
Geometric volume
80 cm3
Shaft dimension
ISO 8x32x36
Direction of rotation
Right-handed
Flange
ISO
Maximum working/short-term pressure
250/300 bar
Suction hole size
G 1-1/4" (5/4")
Pressure hole size
G 3/4"
Maximum working/short-term speed
2300 rpm
Series
MDS
Manufacturer
OMFB
Product weight
12.00 kg
Pump type
MDS-80
Rotation direction
Clockwise
Displacement (cc)
77.25
Flange type
4 holes flange
Shaft type
14 splined shaft
Maximum pressure (bar)
300.0
Weight (kg)
11.93
Thread O, inlet (inch)
1-1/4
Thread O, outlet (inch)
3/4
