0511525606
R918C03469
R918C03689
0005001122 EVOBUS
A0005001122
A6285001822
AZMF-11-011UCB20PL-S0040
61130101300
A0511525606
-------------
Weight (kg)
3,54
Brand
Bosch-Rexroth
Operating pressure (bar)
210
Manufactured size
F
Max. revolution (rpm)
3500
Max. pressure (bar)
250
Material housing
aluminum
Displacement (cm3/r)
11
Specification drive
shaft conical 1:5
o shaft/hub (mm)
17
Center o flange (mm)
80
o oil connection A (mm)
20
Mounting oil connection A
hole circle 35 mm M 6
o oil connection B (mm)
15
Mounting oil connection B
hole circle 40 mm M 6
Direction of rotation
right
Assembly flange drive
4-hole 100x72 mm M 8
Usage
fan drive
