0511725025
0005002322 MERCEDES
A0005002322 MERCEDES
3100669
0510625022
0510425009
209130056-209130134
209130135
AZMN-11-025RCB20PB-S0098
--------------------
Weight (kg)
6,413
Brand
Bosch-Rexroth
Operating pressure (bar)
210
Manufactured size
N
Max. revolution (rpm)
3000
Max. pressure (bar)
240
Material housing
aluminum
Displacement (cm3/r)
25
Specification drive
shaft conical 1:5
o shaft/hub (mm)
20
Center o flange (mm)
100
o oil connection A (mm)
26
Mounting oil connection A
hole circle 55 mm M 8
o oil connection B (mm)
18
Mounting oil connection B
hole circle 55 mm M 8
Direction of rotation
right
Assembly flange drive
4-hole 132x88.5 mm M 10
Usage
fan drive
