HIDRAULIČNA PUMPA OMFB LTMH-112, ISO, Bi-directional

10503311121
14562036 HYVA
113L-BI-4H-C250BAR
113L-BI-4H5-4P-20BSP20-250
Hyva - 14562041
OMFB LTMH-112
1528446 DAF

--------------

Pump type
LTMH 112

Rotation direction
Bi-directional - Right-handed, Left-handed, Bi-directional

Displacement (cc)
112.00

Flange type
4 holes flange

Shaft type
14 splined shaft

Maximum pressure (bar)
240.0

Weight (kg)
21.25

Suction hole size
G 1-1/4" (5/4")

Pressure hole size
G 1-1/4" (5/4")

Shaft dimension
ISO 8x32x36

Flange
ISO

Maximum working/short-term pressure
205/240 bar

Maximum working/short-term speed
1800/2700 rpm

Series
LTMH
