3P206-2-38G M C
3P206-2-38GMC
3P206238GMC
62300622000
-------------
2 x Couplings 3/8":
BSPP 3/8" FEMALE - ISO 1179-1
Flow Rate:
40 (l/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
Seals:
NBR & PUR
Weight:
1112 g
Brand
Faster
Can be coupled under residual pressure
yes
Certified according to ISO
yes
Connection type
internal thread
Coupling situation
can be coupled under residual pressure
Coupling type
flat sealing
Electrical connections
without
Material housing
aluminum/steel
Max. flow rate (l/min)
40
Nominal diameter (mm)
10
Operating pressure (bar)
250
Sealing
60° inner cone
Thread internal (inches)
G 3/8
Type
P206
Version multi-coupling
2-fold
Weight (kg)
1,24
