3781724
20100101025 - OMFB
201-001-01025
SF36634 - SUNFAB
SAM-025W-N-DL4-L35-S3G-100
61100172700
------------
Assembly flange drive
4-hole 80x80 mm
Brand
Parker
Displacement (cm3/r)
25,6
Leakage oil connection
1/2 inch internal thread
Material housing
aluminum
Max. pressure (bar)
350
Max. revolution (rpm)
3000
Max. torque (Nm)
142
Oil connection A
3/4 inch internal thread
Oil connection B
3/4 inch internal thread
Operating pressure (bar)
250
Power (kW)
20
Specification drive
shaft 8x32x36
Type
F1-25
Weight (kg)
8,5
o shaft/hub (mm)
34,9
