3781780
61100173100
ALTERNATIVA:
20100101084 - OMFB
201-001-01084
SF36640 - SUNFAB SAM-084W-N-DL4-L35-S3G-100
------------
Assembly flange drive
4-hole 80x80 mm
Brand
Parker
Displacement (cm3/r)
81,6
Leakage oil connection
1/2 inch internal thread
Material housing
aluminum
Max. pressure (bar)
350
Max. revolution (rpm)
2000
Max. torque (Nm)
453
Oil connection A
1 inch internal thread
Oil connection B
1 inch internal thread
Operating pressure (bar)
250
Power (kW)
41
Specification drive
shaft 8x32x36
Type
F1-81
Weight (kg)
12,5
o shaft/hub (mm)
34,9
