BKH15L1311131
BKH-15L
BKH 15L 13 1113 1
M22x1,5/o15 BKH 15L 13 1113 1
62300010600
-----------
Length (mm)
33,5
Thread external A metric
M 22x1,5
Thread external B metric
M 22x1,5
Nominal diameter (mm)
13
Production series
light
For FI tube A (mm)
15
For FI tube B (mm)
15
Surface
galvanized
Type
2/2-way
Ball bore form
channel
Mounting bore (mm)
without
Width across flats square (mm)
9
Width across flats line connection (mm)
30
Material
steel
Tube AD series
15 L
Weight (kg)
0,41
Brand
Pister
Max. operating pressure (bar)
500
