1292070
1047387 ALT.
MSG44/520
58100158900
--------------
OPCIONALNO:
RUKOHVATI: 1063746, 1063748
KONZOLA: 143305
--------------
Additional settings
weight setting manual
Air supply
without
Brand
Grammer
Color cover
anthracite/green/silver
Comfort features
fore/aft isolator
Control lever support console
without
For mount EPS
no
Height setting (mm)
80
Horizontal adjustment (mm)
210
Lumbar support
without
Material seat cover
textile
Model designation
Universo Basic Plus
Position operating element
left
front
Spring deflection (mm)
80
Suspension
mechanical
Swivel adapter
without
Track width (mm)
260
Type designation
MSG44/520
Usage
tractor
crane
Weight (kg)
30
Weight setting to (kg)
130
Width seat (mm)
590
Width seat cushion (mm)
450
