D130PP164C0
61100028500
Weight (kg)
4,5
Info 1
mounting screws with
Info 2
max. 40 Nm +/- 5 Nm pull
Max. operating pressure (bar)
350
Surface
painted
Type
DMP130-160
Material
cast steel
Flow rate tilting operation (l/min)
130
Flow lowering operation (l/min)
130
Set pressure (bar)
160
Connection pressure input
G 3/4 inch internal thread
Connection consumer
G 3/4 inch internal thread
Connection control line
1/8 inch internal thread
Test connection
1/8 inch internal thread
Actuation
pneumatic
