11186652
OMRX315
OMR315
OMR3151510717
1510717
61100427600
------------
Weight (kg)
9.084
Power (kW)
7
Brand
Danfoss
Operating pressure (bar)
100
Max. torque (Nm)
400
Max. revolution (rpm)
195
Max. pressure (bar)
140
Displacement (cm3/r)
310.1
o shaft/hub (mm)
25
Standard drive DIN
6885
Material housing
cast steel
Type
OMRX 315
Max. oil flow (l/min)
60
Specification drive
cylindrical shaft thread internal
Optional equipment valve
check valve
Oil connection A (inches)
1/2 internal thread
Oil connection B (inches)
1/2 internal thread
Leakage oil connection (inches)
1/4 internal thread
Assembly flange drive
2-hole oval (A2) M 12
