151F0500
OMS80
151F0200
OMS80151F0500
61100108200
-----------
Continuous power max.
15.5 kW
Continuous rotation max.
810 rpm
Dimension L
167 mm
Dimension L1
14 mm
Dimension L2
124 mm
Dimension L3
67 mm
Displacement
80.5 cm3
Drainport
G 1/4 BSP
Holes circle
106.4 mm
Intrastat code
84122981
Mounting flange
Square 82,5
Number of mounting holes
4
Oil viscocity recommended
20 - 75 cSt
Port position
Side
Pressure drop continuous max.
210 bar
Recess
82,5 mm
Shaft diameter
32 mm
Shaft keyway
10,0 mm
Shaft type
Cylindrical
Torque continuous max.
240 Nm
Working ports
G 1/2 BSP
