3781050
F1-51-R
F1051-R
F1-051-R
61100111400
0523770
EP1399A
EP1401A
lijevo F1-51-L, 3781051
SAP-056R-N-DL4-L35-S0s-000
desno A17FO45/10NRWK0E81-0, lijevo A17FO45/10NLWK0E81-0
desno SCP-047R-N-DL4-L35-S0S-000, lijevo SCP-047L-N-DL4-L35-S0S-000
desno SCP-047R-N-DL4-H35- S0S-000 lijevo SCP-047L-N-DL4-H35-S0S-000
desno SCP-056R-N-DL4-L35-S0S-000 lijevo SCP-056L-N-DL4-L35-S0S-000
desno SCP-056R- N -DL4-H35-S0S-000, lijevo SCP-056L-N-DL4-H35-S0S-000
F01051R
F1051R
60100110553
41813 SCHWARZMULLER
Weight (kg)
8,5
Brand
Parker
Operating pressure (bar)
350
Max. revolution (rpm)
2450
Direction of rotation changeable
yes
Max. pressure (bar)
400
Delivery rate (cm3/r)
51,1
Direction of rotation
right
Standard drive DIN
5462
Material housing
aluminum
Construction form
inclined axis
Type
F1-51-R
Specification drive
shaft 8x32x36
Assembly flange drive
4-hole 80x80 mm
Suction connection
plugged in
Pressure connection
G 3/4 inch internal thread
