0511725318
0511725301
AZMG-11-032LCB20MB
0005001122
A0005001122
61130106000
Weight (kg)
10,667
Brand
Bosch-Rexroth
Operating pressure (bar)
180
Manufactured size
G
Max. revolution (rpm)
2800
Max. pressure (bar)
210
Material housing
aluminum
Displacement (cm3/r)
32
Specification drive
shaft conical 1:5
o shaft/hub (mm)
25
Center o flange (mm)
105
o oil connection A (mm)
18
Mounting oil connection A
hole circle 55 mm M 8
o oil connection B (mm)
26
Mounting oil connection B
hole circle 55 mm M 8
Direction of rotation
left
Assembly flange drive
4-hole 145x102 mm M 10
Usage
fan drive
