10501110833
1527304 DAF
22247082 LIWA
DPA30-82CCW
NPH82SX
--------------
Max operating pressure (bar)
200.0
Pump type
Gear
Pump type
NPH 82
Rotation direction
Anti-clockwise, Left-hand drive
Max flow (L/min)
82
Displacement (cc)
81.08
ISO approval type
NPH 82
Flange type
4 holes flange
Shaft type
14 splined shaft
Maximum pressure (bar)
220.0
Weight (kg)
14.64
Suction hole size
G 1-1/4" (5/4")
Pressure hole size
2x G 3/4"
Shaft dimension
ISO 8x32x36
Flange
ISO
Maximum working/short-term pressure
205/230 bar
Maximum working/short-term speed
1900/2500 rpm
Product weight
15.50 kg
