0511555
61100012000
-----------
Assembly flange drive
4-hole 80x80 mm
Brand
Leduc
Construction form
straight
Delivery rate 1 (cm3/r)
52
Delivery rate 2 (cm3/r)
52
Direction of rotation
left=right
Material housing
cast steel
Max. pressure (bar)
500
Max. revolution (rpm)
1400
Operating pressure (bar)
400
Pressure connection 1
3/4 inch internal thread
Pressure connection 2
3/4 inch internal thread
Specification drive
shaft 8x32x36
Standard drive
DIN 5462
Suction connection
2 inch internal thread
Type
PA 2-50
Weight (kg)
23,5
