3781760
F1-061-M
F1-61-M
F1061M
201-001-01064
ALTERNATIVE - 20100101064 - OMFB
SF36638 - SUNFAB - SAM-064W-N-DL4-L35-S3G-100
61100173000
--------
FI shaft/hub (mm)
34,9
Weight (kg)
8,5
Power (kW)
34
Brand
Parker
Operating pressure (bar)
250
Max. torque (Nm)
331
Max. revolution (rpm)
2200
Max. pressure (bar)
350
Displacement (cm3/r)
59,5
Material housing
aluminum
Type
F1-61
Specification drive
shaft 8x32x36
Assembly flange drive
4-hole 80x80 mm
Oil connection A
3/4 inch internal thread
Oil connection B
3/4 inch internal thread
Leakage oil connection
1/2 inch internal thread
