0510565322
R918C01127
S0207
AZPFF-10-011-008-L
AZPFF-10-011/008LCXXXXXMB-S0207
6005020872 RENAULT
6005020874 RENAULT
6005030950
7700563531
7700013742
7700035327
7700706110
35285709
35281570
35281566
35281548
35281530
2068-R88
06-35281-566
1515500013
62000011004
-----------
Weight (kg)
4,9
Brand
other
Operating pressure (bar)
180
Manufactured size
F
Max. revolution (rpm)
3500
Max. pressure (bar)
180
Material housing
aluminum
o shaft/hub (mm)
17
Center o flange (mm)
63,5
Direction of rotation
left
Version
double pump
Delivery volume (cm3/r)
14/8
Specification drive
shaft conical 1:5
o suction connection (mm)
20
Mounting suction connection
hole circle 40 mm M 6
o pressure connection (mm)
13,5
Mounting pressure connection
hole circle 30,2 mm M 6
Optional equipment valve
without valve
Assembly flange drive
2-hole 96.8 mm M 10
Usage
hoist
Usage
steering
