0523820
Palfinger - EP1394
HDS12
60100110123
60100110129
Hydroleduc XPi12 0523820
SCP012 20472
SCP012 20472R
SAP012 23012
23012R
EP1394A
SUNFAB: SCP-012R-N-DL4-L35-S0S-000
SCP-012L-N-DL4-L35-S0S-000 SCP-012R-N-DL4-H35-S0S-000
SCP- 012L-N-DL4-H35-S0S-000,
PARKER:
F1-12-R
3782212
F1-12-L
3782211
61100351900
------------------
Weight(kg)
10,2
Brand
Leduc
Operating pressure(bar)
380
Max.revolution(rpm)
3150
Direction of rotation changeable
yes
Max.pressure(bar)
420
Deliveryrate(cm3/r)
12
Direction of rotation
left
Direction of rotation
right
Standard driveDIN
5462
Material housing
caststeel
Construction form
inclinedaxis
Type
XPI12
Specification drive
shaft8x32x36
Assembly flangedrive
4-hole 80x80mm
Suctionconnection
plugged in
Pressure connection
G3/4 inchinternal thread
