3VDMR000N00
61100045100
3VDMR000000
može se koristiti kao analog sljedećih ventila:
Razdjelnik OMFB 3/2 sa pneumatskim upravljanjem SEL 250-2, šifra: 12102200132 (121-022-00132);
Razvodnik Binotto 3/2 sa pneumatskim upravljanjem SEL 250-2, šifra: 12102200132bi (121-022-00132bi) ID 00002139
Width (mm)
101
Weight (kg)
2,68
Height (mm)
75
Length (mm)
191
Brand
Interpump (IPH)
Type
VDMR
Max. flow rate (l/min)
200
Max. operating pressure (bar)
350
Material
cast steel
Connection pressure input
1 inch internal thread
Connection pneumatic
push in 6x1
Max. pneumatic pressure (bar)
12
Connection pressure output 1
3/4 inch internal thread
Connection pressure output 2
3/4 inch internal thread
