400C2101000
61100027300
PZBNM3T6
CP2000-1
14750665 HYVA
14752165H
14750667
9013213
9012013
9010513
9010413
D143 BERTOCCO
Width (mm)
56
Weight (kg)
0,38
Height (mm)
155
Info 1
connection ventilation: push in 6x1
Length (mm)
64
Brand
Hydrocar
Material
aluminum
Max. operating pressure (bar)
12
Number of connections pneumatic
4
Position connection
bottom
Connection pressure input
push in 6x1
Connection pressure output 1
push in 6x1
Connection pressure output 2
push in 6x1
Mounting method
panel mounting
Connection pressure switch
blade terminal 6.3 mm
With signal lamp
no
Switch position
arrester neutral lifting lowering
Optional equipment
without
