3780337
VP1-075-L
VP01-075-L
TXV60; TXV-60;
0512500
0512505
SVH-062
SVH62
VP1-75
3786172
3780337
3780336
3786171
Max. torque (Nm)
375
Max. revolution (rpm)
2100
Direction of rotation changeable
no
Delivery rate (cm3/r)
75
Direction of rotation
left
Standard drive DIN
5462
Differential pressure valve (bar)
{lt} 35
Pressure connection
1 inch internal thread
Running fit connection (inches)
1/4 internal thread
Type
VP1-075-L
Assembly flange drive
4-hole 80x80 mm
Weight (kg)
27
Operating pressure (bar)
350
Brand
Parker
Suction connection
1 1/4 inch internal thread
Max. pressure (bar)
400
Material housing
cast steel
Leakage oil connection
1/4 inch internal thread
Specification drive
shaft 8x32x36
