3780336
3786171 - CRNO OBOJANA
0512510
TXV75
VP175R
KVA7VO80DRS/63r-Mek-Mek64
A18VO080DRS00/11NRWK0E810-0
A17VO080DRS00/10MRWK0E81-0
R902207688
EP769R
61100015600
Weight (kg)
28
Brand
Parker
Operating pressure (bar)
350
Max. torque (Nm)
375
Max. revolution (rpm)
2100
Direction of rotation changeable
no
Max. pressure (bar)
400
Delivery rate (cm3/r)
75
Direction of rotation
right
Standard drive DIN
5462
Specification drive
shaft 8x32x36
Assembly flange drive
4-hole 80x80 mm
Type
VP1-075-R
Differential pressure valve (bar)
{lt} 35
Suction connection
1 1/4 inch internal thread
Pressure connection
1 inch internal thread
Leakage oil connection
1/4 inch internal thread
Running fit connection (inches)
1/4 internal thread
Material housing
cast steel
