1439933
1439933A
1439933-A
9609107904
A9609107904
A96091093101
9609109301
9609107601
A9609107601
A9609109301
A9609107501
A96091076049L26
96091076049L26
A96091076049J81
96091076049J81
1401907
58100197200
------------
only for vehicles without seat belt tensioners and/ or proximity control The armrests are optional extras and must be ordered separately.
Mercedes Actros IV, V model designation 963 (from 2011)
Mercedes Antos model designation 963
Mercedes Arocs model designation 964
-----------
Additional settings:
weight setting automatic
backrest adjustment
seat cushion inclination adjustment
shock absorber adjustable
height setting
seat cushion depth adjustment
Air supply
of vehicle
Backrest adjustment (°)
-20,9
32,3
Brand
Grammer
Color cover
anthracite
Comfort features:
integrated head restraint
seat heating
shoulder adjustment
quick lowering
fore/aft isolator
seat backrest contour adjustment
passive seat climate control
Control lever support console
without
For mount EPS
no
Height setting (mm)
145
Horizontal adjustment (mm)
220
Inclination adjustment (mm)
55
Inclination adjustment (°)
-2 to 12
Lumbar support
pneumatic
Material seat cover
textile
Model designation
Roadtiger Comfort
Position operating element
front
left
Safety equipment:
integrated 3-point belt system
belt height adjustment
seat belt buckle sensor
Spring deflection (mm)
55
Suspension
pneumatic
Swivel adapter
without
Track width (mm)
280
Type designation
MSG115/933
Usage
truck driver
Voltage (V)
24
Weight (kg)
56
Weight setting to (kg)
190
Width seat (mm)
582
Width seat cushion (mm)
502
