V1DF21-199
RML79198C1
500055350
41298917
FE107305
041298917 IVECO
0004690299 IVECO
0041298917
500329566
SP559198-K01
7.12024
030607020306
AU349198-K01
1TS270-27-C
14166208311
-------------
Air connection
2 separate overlapping bottom
Attachment type at bottom
1 stud bolt
Attachment type at top
1 stud bolt
Brand
Vibracoustic
Height rolling piston (mm)
165
Info 1
length diaphragm max. length 550 mm
Inscription CF Gomma
1TS 270-27
Inscription Vibracoustic
V1DF21
V1DF21-199
Material rolling piston
steel
Measures air connection
M 16x1,5
Measures mounting bottom
M 14
Measures mounting top
M 14
Type of construction
rolling bellows
Version
complete
Weight (kg)
9,386
o rolling piston (mm)
250
