0510725089
62000037900
132575005CASE
155700750003CASE
04450516KHD
1-32-575-005STEYR
R918BG2273
AZPN-21-032RDCXXMB
----------------
Weight (kg)
6,056
Brand
Bosch-Rexroth
Max. revolution (rpm)
2800
Max. pressure (bar)
200
Material housing
aluminum
FI shaft/hub (mm)
21,80
Center FI flange (mm)
101,6
Direction of rotation
right
Version
single pump
Delivery volume (cm3/r)
32
Specification drive
splined shaft ANSI B 92.1
FI suction connection (mm)
42
Mounting suction connection
M 42x2 usable depth 20 mm
FI pressure connection (mm)
22
Mounting pressure connection
M 22x1,5 usable depth 14 mm
Optional equipment valve
without valve
Assembly flange drive
2-hole 174 mm
